Laser Welding Machine NF-LW3-K 3000
Article Nr. NF-LW3-K 3000
Laser Welding Machine NF-LW3-K 3000
Handheld Laser Welding Machine with Automatic Wire Feeder - 3000 Watt - Water-Cooled
The compact, hand-held laser welder NF-LW3-K 3000 includes a 10 m hose package, a manual welding gun incl. automatic wire feed. The device is mounted on fixed and swivel castors. German operating software, manual and professional service!
More information and technical details can be found in the data sheet and brochure under "Downloads".
We reserve the right to make technical changes and changes in shape, color and/or weight within reason.
Advantages
- Precise Welding Process: The handheld laser welding device enables precise and targeted welding of materials.
- High Welding Quality: The laser beam produces high-quality welds with minimal distortion and high strength.
- Low Heat Input: The focused laser beam heats only a small area, minimizing the heat input into the workpiece. Integrated air cooling allows for extended welding tasks without issues.
- Versatile Application Possibilities: The device can be used on a variety of materials, including metals, plastics, and alloys.
- No Additional Consumables: In contrast to other welding methods, no additional consumables such as welding wires or electrodes are required.
- Low Post-Processing Effort: Precise welding control reduces the need for post-processing and grinding.
- Efficient and Fast Welding Speed: The handheld laser welding device enables a fast and efficient welding process, resulting in time savings.
- Lower Thermal Deformation: The low heat input minimizes the deformation of the workpiece during welding.
- Flexibility: The handheld device allows access to hard-to-reach areas and enables precise welds in various applications.
- Automatability: Handheld laser welding devices can be integrated into automated production lines to further increase productivity.
Properties
Which materials can be welded with it?
- Stainless steel
- Black steel
- Aluminum
- Copper
- Brass
- Titanium
- Alloys such as Inconel, Monel, Hastelloy
- Automotive and aerospace parts
- Kitchen appliances and household goods
- Precision and precision engineering parts
Details
What is meant by cost and time savings?
Modell: | NF-LW3-K 3000 |
Voltage & Frequency: | 380 V / 50 Hz |
Laser power: | 3000 W |
Laser frequency: | 50-5000 Hz |
Wavelength: | 1070 nm +- 3nm |
Stainless steel Penetration depth: | 6,0 mm |
Black steel Penetration depth: | 6,3 mm |
Aluminum Penetration depth: | 6,0 mm |
Weld seam width: | 0-5 mm |
Hosepack length: | 10 m (Deviation on request) |
Welding pistol: | Plastic (optional Aluminium) |
Wire feed specification: | 0,8/1,0/1,2/1,6 mm |
Overall performance: | 13 kW |
Application environment: | Temperature: 0 C° - 45 C° | Air Humidity: <95% |
Cooling type: | water-cooled |
Function: | welding |
Machine weight: | 177 kg |
Machine dimensions: | 137 x 69 x 126 cm |
