Laser Cleaning Machine NF-LC-S 200 / NF-LC-M 200

Article Nr. NF-LC-S 200 - 2557 / NF-LC-S 200 - 2128 / NF-LC-M 200 - 2126

The handheld laser cleaning device NF-LC-S 200 & NF-LC-M 200 was developed for professional use in industry and trade. It meets all relevant requirements in accordance with Performance Level d and is therefore approved for safe operation in industrial applications.

Product specifications:

  • Laser power: 200 watt

  • Cooling: Integrated air cooling

  • Spot mode: Single or Multi

  • Safety standard: Performance Level d

  • Device type: Handheld

  • Expandability: Connection to automated systems possible on request

Features and benefits:

  • Efficient cleaning: Fast and thorough removal of contaminants with reduced labor

  • Environmentally friendly: Cleaning without chemical cleaning agents – saves costs and protects the environment

  • Gentle cleaning: Removes contaminants precisely without damaging the surface

  • Flexibility: Suitable for hard-to-reach areas and a wide range of applications

  • Material variety:

    • Metals

    • Plastics

    • Glass

    • Ceramics

    • Stone

    • Wood

    • Rubber

    • Painted and coated materials

  • Areas of application: Industrial cleaning, rust removal, removal of oil, paint, and varnish, preparation for coatings, monument preservation, mechanical engineering, automotive industry, repair, maintenance, ...



We offer a wide range of accessories and safety equipment for our laser cleaning systems – complemented by expert service and technical support.

If you require a laser safety officer, we offer direct placement through our website – further information can be found under Laser Safety Officer Training.

Technical modifications as well as changes in shape, color and/or weight are subject to reasonable variations.

Model: NF-LC-S 200 NF-LC-S 200 NF-LC-M 200
Item number: 2557 2128 2126
Output power: 200 W 200 W 200 W
Voltage & Frequency: 230 V / 50 Hz 230 V / 50 Hz 230 V / 50 Hz
Spot Mode: single single multi
Max. single pulse energy: 1.5 mJ 2 mJ 5 mJ
Working distance / scan width: 185-438 mm / 105-300 mm (depending on the field mirror model*) 185-438 mm / 105-300 mm (depending on the field mirror model*) 185-438 mm / 105-300 mm (depending on the field mirror model*)
20µm Flash rust: 7.2 m²/h 7.2 m²/h 8.6 m²/h
20µm Oil contamination: 8.6 m²/h 8.6 m²/h 10.3 m²/h
20µm Paint/Varnish: 4.8 m²/h 4.8 m²/h 5.3 m²/h
5µm galvanized sheet metal: 6.4 m²/h 6.4 m²/h 7.5 m²/h
Floor or wall surface: 6.8 m²/h 6.8 m²/h 7.2 m²/h
Car paint: 0.9 m²/h 0.9 m²/h 1 m²/h
Aluminum oxide film: 3.6 m²/h 3.6 m²/h 4.5 m²/h
Hot rolled steel oxide film: 0.45 m²/h 0.45 m²/h not very efficient
Overall performance: 1 kW 1 kW 1 kW
Application environment: Temperature: 0 C° - 45 C° | Air Humidity: <95% Temperature: 0 C° - 45 C° | Air Humidity: <95% Temperature: 0 C° - 45 C° | Air Humidity: <95%
Function: cleaning cleaning cleaning
Machine weight: 54 kg 34 kg 34 kg
Machine dimensions (L x W x H): 75 x 25 x 63 cm 63 x 29 x 50 cm 63 x 29 x 50 cm
Cooling system: air-cooled air-cooled air-cooled

We will be happy to provide you with the technical data sheets as a PDF on request.

Field mirror model* (standard F254) F160 F210 F254 F330 F420
Working distance mm 185 240 285 345 438
Scan width mm 105 130 150 175 200
